HCPE Series Swimming Pool Pump 220-240V (250W-370W)

HCPE Series Swimming Pool Pump for Spa & Swimming Pool Systems

The HCPE Series Swimming Pool Pump is a compact self-priming pool pump designed for small swimming pools, above-ground pools, spa pools, and pool filtration systems. Its compact size makes it easy to install in tight spaces, while the huge pro-filter reduces cleaning maintenance.

Operating at 220-240V / 50Hz with three-phase 400V / 50Hz versions available, the HCPE Series Swimming Pool Pump delivers a maximum flow of up to 220 L/min with heads up to 11 meters, making it an economical choice for small pool systems in European, Asian, and other 50Hz power supply markets.

Key Features

• Single or three phase options
• Silent operation for reduced noise
• Concise and compact design
• Class F insulation
• Maximum liquid temperature ≤60°C
• Chemical-resistant construction for swimming pool water
• IPX5 waterproof protection
• Anodized aluminum motor body
• Built-in overload protection
• Huge pro-filter for less cleaning maintenance
• Heightened pump base keeps the pump away from water or moist environments
• Built-in drain device for easy maintenance
• Self-priming design for quick water pickup
• High-efficiency motor with stable flow output
• Durable construction for long service life
• CE, SAA, CB, TUV certified

Why Choose the HCPE Series

The HCPE Series Swimming Pool Pump is built for compact, low-maintenance pool operation. The self-priming design starts quickly, the huge pro-filter catches debris before it reaches the pump, and the chemical-resistant construction stands up to pool water treatment chemicals. Class F insulation and IPX5 waterproof protection complete a dependable package for small pool duty.

• Designed and tested for continuous duty in European, Asian, and other 50Hz markets
• Stable water flow with low vibration and quiet operation
• High-quality mechanical seal resists pool and spa chemicals
• Built-in overload protection for safe long-term operation
• CE, SAA, CB, TUV certified for export markets

Quality & Certification

The HCPE series is manufactured under an ISO9001 quality management system, with every pump tested before shipment. All models carry CE, SAA, CB, and TUV certification, so the HCPE Series Swimming Pool Pump meets the requirements of international export markets and can be installed with confidence in residential and commercial projects.

Performance Curves

The performance curve of the HCPE Series Swimming Pool Pump shows the relationship between flow rate and head at 2860 r/min, helping you select the right model for your spa or swimming pool system.

Technical Parameter List

Model	Power	V/Hz	Qmax (L/min)	Hmax (Meter)	Self-priming (m)	Fitting Size (mm)	G.W (kg)	Packing Size (mm)	Qty/20′
HCP250E	250W/0.35HP	220-240V / 50Hz	170	8	6.5	40/48.5	5.6	490×200×265	1078
HCP250E-3P	250W/0.35HP	400V / 50Hz	170	8	6.5	40/48.5	5.6	490×200×265	1078
HCP370E	370W/0.5HP	220-240V / 50Hz	220	11	7	40/48.5	6.5	490×200×265	1078
HCP370E-3P	370W/0.5HP	400V / 50Hz	220	11	7	40/48.5	6.5	490×200×265	1078

Available Models

The HCPE Series Swimming Pool Pump is available in the following models:

• HCP250E (250W/0.35HP)
• HCP250E-3P (250W/0.35HP)
• HCP370E (370W/0.5HP)
• HCP370E-3P (370W/0.5HP)

Every model of the HCPE Series Swimming Pool Pump is available with the standard fitting size shown in the table, and different power options are available to match various spa and swimming pool system requirements.

Customization & OEM Service

All models in the HCPE series can be customized for OEM and ODM projects. Options include different power ratings, 50Hz or 60Hz voltage configurations, single-phase or three-phase motors, special fittings, and private-label packaging. We support export documentation, making the HCPE Series Swimming Pool Pump a flexible choice for spa equipment brands, pool equipment suppliers, and project buyers.

Packaging & Shipping

Each HCPE Series Swimming Pool Pump is individually packed in a sturdy carton measuring 490×200×265 mm. Depending on the model, one 20-foot container can hold 1078 units, which keeps freight costs predictable for regular export shipments. All pumps are inspected before packing to ensure reliable arrival at your warehouse or project site.

Applications

The HCPE Series Swimming Pool Pump is suitable for:

• Swimming pools
• Above-ground pools
• Spa pools
• Pool filtration systems
• Pool water circulation
• Pool cleaning systems
• Residential pools
• Commercial pools

Designed for dependable performance, the HCPE Series Swimming Pool Pump delivers a maximum flow of 170 to 220 L/min across 250W to 370W, making it an excellent choice for OEM manufacturers, spa equipment suppliers, swimming pool contractors, and distributors seeking reliable pump solutions.
